“WWSCRF”: Wireless Wheel and Axle Weighing Pads

Wireless pads designed for creating wheel and axle vehicle weighing stations, avoiding the hassle of connecting cables between the pads and the indicator. Pads designed for creating weighing stations for large vehicles (vans, trucks, tankers, tractor-trailers, etc.); particularly accurate and sturdy, with attention to details.

FEATURES

• Pad dimensions: 564x511mm. Height 58mm. Weight approximately 18kg.
• Loading surface: 564x400mm.
• Very handy.
• Sturdy structure, made in special alluminum, which guarantees lightness and makes these suitable also for harsh working conditions.
• Stainless steel load cells.
• Overall IP68 protection.
• Sturdy built-in weight indicator with waterproof keyboard and backlit display.
• Built-in radio module for weight transmission to a remote indicator or external device.
• Integrated wheels for easy transport and positioning.
• Power supply: internal rechargeable battery (about 40 h battery life) and charger included (to not use as power adaptor).
• Special vulcanized nonslip rubber applied under the pad, for good grip on all types of surfaces.
• The WWS pads are patented; the number is 1.342.302.
• Available in legal for trade approved version.
• Available in high resolution version.

WWSDUAL: Second pad option

The WWSDUAL option allows you to connect the analog WWS pad directly to the WWS RF pad, without adding modules or batteries, achieving a compact axle weighing scale, versatile and lower cost.

You can use the integrated indicator to totalize axles manually or by remote control, to connect via Bluetooth with tablets and smartphones, or to pair scales and create an axle weighing station using the weight indicators in a suitcase.
